Features:
– 2SAFE proprietary protocol
– Remote programming and management via web environment IP-OPENER MANAGER
– Network connection by TCP/IP or RS485
– Verification by PIN, RFID, 868 Mhz RF or Bluetooth
– Capacity for up to 100,000 users and storage of up to 20,000 events
– 48VDC / 2A output relay
– Input for remote activation pushbutton with optocoupler protection
– Installation in metal cabinet (not included)
– 12Vdc/1.5A power supply (included in metal cabinet)
Product specification:
– Technology: 2SAFE
– No. of doors: 4
– Connection: Ethernet,RS485
– Reading/management type: PIN, proximity, Bluetooth
– Use: Indoor
– RFID Frequency (MHz): 13.56
– Max. records: 20000
– Max. Users: 100000
– Max. Network controllers: 64
– Max. Readers by Red.: 384
– Mounting: DIN rail
– Requires a license: No
– Format Reports: XLS
– Report generation: Yes
– Management: Companies, calendars, schedules
– Input voltage: 12Vcc
– Maximum working temperature (ºC): 60
– Minimum working temperature (ºC): -10
– Relative humidity work (max.): 85
– Dimensions – High (mm): 90
– Dimensions – Width (mm): 198
– Dimensions – Deep (mm): 34
– Weight (gr.): 595
– 2SAFE proprietary protocol
– Mounting: DIN rail
– Installation in metal cabinet (not included)
